automatic hydrotest pressure test in China for pressure test

Automatic hydrotest pressure test in China for pressure test

MOQ
1 Set
Brand Name
SUNCENTER
Certificate
ISO/CE/SGS
Warranty
13 Months
Packaging
By Plywood case
Shipping Port
Shenzhen/Hongkong
Payment
T/T,Western Union,Credit card.
Transaction method
EXW,FOB,DDP,CIF,CFR
Place of Origin
Guangdong Province, China (Mainland)
Delivery Time
Within 10-15 working days after received deposit
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:

Product application scope and functional characteristics:



Applicable range of air pressure test equipment:

Automobile steering tube, brake pipe, air-conditioning pipe, oil pipe, water pipe cooling, radiator, heater hose, hydraulic equipment, condenser, evaporator, air conditioning filter hose, turbocharging system hose, car brake pump, a cylinder body, a project hydraulic hose, air hose and manifold, rigid pipe, joints, valves, pressure gauges, pressure vessel, pressure transmitter etc.



Function and characteristics of air pressure test equipment:

The main components is the mature products produced by our company

The piping system with non welded connection

The test fluid system and driving fluid system are separated; it is more convenient for test temperature control and test media diversification

The software adopts force control configuration software or written in LABVIEW (computer control)

A variety of ancillary tooling, meet different specimens of installation

In the testing process, the pressure can be automatically compensated; time after the bursting pressure decreased rapidly, pressure automatic stop system;

The protection of tooling, special design, can effectively protect the damage of blasting operation personnel and equipment.

The realization computer control function, can be free to set up a water filled exhaust time, holding pressure time, aeration cleaning time, test pressure in the process of the experiment can be set arbitrarily single or multi section pressure maintaining test, can also holding pressure directly after blasting, boost the speed to maintain a constant, can realize stepless adjustment and test data and curve parameters can real-time display, can automatically save the test results, and any print test reports. (computer control)


automatic hydrotest pressure test in China for pressure test-1
automatic hydrotest pressure test in China for pressure test-2


System technical parameters and composition


Model: SHT-DGA10-CC

SHT------- Suncenter High Pressure Test Machine

DGA10-------Sucneter DGA10 gas(air) booster pump

CC------- Computer control

Drive source: clean compressed air

Driven by compressed air pressure: 3-8bar (recommended driving pressure of ≤8bar)

The maximum air consumption: 460LN/min (6 kg)


Working principle


automatic hydrotest pressure test in China for pressure test-3


automatic hydrotest pressure test in China for pressure test-4
  • Air pressure (Air leakage) test machine


Technical specification


Model

Pressure boost ratio

Min. gas
     Inlet pressure
     PA (bar)

Max.gas
     Inlet pressure
     PA (bar)

Max. gas
     outlet pressure PB (bar)

 Driven air pressure  PL

Formula to
     calculate gas outlet pressure PB

Connection:
     Gas Inlet /
     Gas outlet (ZG thread)

Max. flow at driven air pressure of 6bar (L/min)

SHT-DGA02-CC

2:1

1.0

16

16

2-8 bar

2X PL

1/2 / 1/2

960 (at PA of 6 bar )

SHT-DGA05-CC

5:1

0

40

40

2-8 bar

5XPL

1/2 / 1/2

680(at PA of 6 bar )

SHT-DGA10-CC

10:1

3.5

80

80

2-8 bar

10XPL

3/8/ 3/8

210(at PA of 10 bar )

SHT-DGT25-CC

25:1

0.1

10

200

 2-8 bar

25XPL

1/4/ 1/4

136(at PA of 8 bar )

SHT-DGT40-CC

40:1

0.1

10

320

 2-8 bar

40XPL

 1/4/1/4

124(at PA of 8 bar )

SHT-DGT60-CC

60:1

0.1

10

480

2-8 bar

60XPL

 1/4/1/4

84(at PA of 8 bar )

SHT-DGT100-CC

100:1

0.1

10

800

2-8 bar

100XPL

1/4/ M14*1.5

63(at PA of 8 bar )


video





The production of Suncenter hydrotest pressure involves several stages. They include lamination staking, slot insulating, winding, wire-leads termination, and electrical testing. It provides a style look and comfortable grip
Suncenter hydrotest pressure is developed with pretreatment, refined filtration, cleaning and sterilization systems. The R&D team strives to achieve the best water treatment effect by improving its systems. It is completely UV resistant and has reliable colorfastness
Suncenter pipe pressure test pump has passed performance tests and quality assurance tests in the phone accessory industry. It is certified under CCC, CE, UL, and GOST. It will continue to look good, as the leather is able to heal itself of blemishes and scratches
Suncenter hydrotest pressure meets a variety of international standards for electric appliances. They are CARB, FCC, ETL, UL, CB, CCC and so on. This product is not easy to deform
Suncenter pipe pressure test pump is the outcome of complicated electric knowledge. It is developed taking many things into consideration, including the design of circuit boards, components, circuits, and the whole product shape. With a stable structure, it protects the object insides against shock
The establishment of quality control system ensures its high quality. The materials make it antibacterial and antifungal
