Product application scope and functional characteristics:

Applicable range of air pressure test equipment:

Automobile steering tube, brake pipe, air-conditioning pipe, oil pipe, water pipe cooling, radiator, heater hose, hydraulic equipment, condenser, evaporator, air conditioning filter hose, turbocharging system hose, car brake pump, a cylinder body, a project hydraulic hose, air hose and manifold, rigid pipe, joints, valves, pressure gauges, pressure vessel, pressure transmitter etc.

Function and characteristics of air pressure test equipment:

The main components is the mature products produced by our company

The piping system with non welded connection

The test fluid system and driving fluid system are separated; it is more convenient for test temperature control and test media diversification

The software adopts force control configuration software or written in LABVIEW (computer control)

A variety of ancillary tooling, meet different specimens of installation

In the testing process, the pressure can be automatically compensated; time after the bursting pressure decreased rapidly, pressure automatic stop system;

The protection of tooling, special design, can effectively protect the damage of blasting operation personnel and equipment.

The realization computer control function, can be free to set up a water filled exhaust time, holding pressure time, aeration cleaning time, test pressure in the process of the experiment can be set arbitrarily single or multi section pressure maintaining test, can also holding pressure directly after blasting, boost the speed to maintain a constant, can realize stepless adjustment and test data and curve parameters can real-time display, can automatically save the test results, and any print test reports. (computer control)

automatic pressure test kit leakage application for pressure test-1

automatic pressure test kit leakage application for pressure test-2

System technical parameters and composition

Model: SHT-DGA10-CC

SHT------- Suncenter High Pressure Test Machine

DGA10-------Sucneter DGA10 gas(air) booster pump

CC------- Computer control

Drive source: clean compressed air

Driven by compressed air pressure: 3-8bar (recommended driving pressure of ≤8bar)

The maximum air consumption: 460LN/min (6 kg)

Working principle

automatic pressure test kit leakage application for pressure test-3

automatic pressure test kit leakage application for pressure test-4

◪ Air pressure (Air leakage) test machine

Technical specification

Model	Pressure boost ratio	Min. gas Inlet pressure PA (bar)	Max.gas Inlet pressure PA (bar)	Max. gas outlet pressure PB (bar)	Driven air pressure PL	Formula to calculate gas outlet pressure PB	Connection: Gas Inlet / Gas outlet (ZG thread)	Max. flow at driven air pressure of 6bar (L/min)
SHT-DGA02-CC	2：1	1.0	16	16	2-8 bar	2X PL	1/2 / 1/2	960 (at PA of 6 bar )
SHT-DGA05-CC	5：1	0	40	40	2-8 bar	5XPL	1/2 / 1/2	680(at PA of 6 bar )
SHT-DGA10-CC	10：1	3.5	80	80	2-8 bar	10XPL	3/8/ 3/8	210(at PA of 10 bar )
SHT-DGT25-CC	25:1	0.1	10	200	2-8 bar	25XPL	1/4/ 1/4	136(at PA of 8 bar )
SHT-DGT40-CC	40:1	0.1	10	320	2-8 bar	40XPL	1/4/1/4	124(at PA of 8 bar )
SHT-DGT60-CC	60:1	0.1	10	480	2-8 bar	60XPL	1/4/1/4	84(at PA of 8 bar )
SHT-DGT100-CC	100:1	0.1	10	800	2-8 bar	100XPL	1/4/ M14*1.5	63(at PA of 8 bar )
